D2 specifications



Wingspan:                                                              5,4 m
Length:                                                                   4,7 m
Wing area:                                                              15 m2

Empty weight prototype:                                   275 kg
Max take-off weight:                                           600 kg
Payload                                                                 325 kg

Performance, all at ISA, sea level, with MTOW

Cruise speed @75%P:                                         240 km/h
Max level speed, full throttle, 5000 rpm          260 km/h
Best climb (at 120 km/h, gear up, MTOW)       850 fpm
Best climb at 500 kg (2 adults, 4 hr fuel)        1300 fpm
Best glide angle (at 150 km/h, gear up)             1:10
Take off over 50′ obstacle                                   500 m
Take off run                                                           350 m
Landing distance over 50′ obstacle                   450 m
Stallspeed:                                                               85 km/h at full gross

Loadfactor:                                                             +/- 6g
Vne:                                                                         300 km/h

Tank content:                                                        120 ltrs

Engine Rotax 912 ULS,
uses 18 l/hr mogas at cruisespeed, 16 l/hr at 220 km/h

Propeller on prototype Woodcomp VAR-2, variable pitch

Construction, main structure aluminum 2024, ribs of hard foam

Landinggear steering monowheel type with rubber compression spring
tailwheel with shock cord suspension
tipwheels with metal spring suspension

Cabin dimensions LxWxH:                       2,2 x 1,46 x 0,94 m
